A broad and modern range of machines
SMV has a broad and modern range of machines. Most of them are automated. We also have a few manual machines for small series and prototypes, or even a single part if that is what you need. Below is a selection of our machines.
Lathes
- Citizen M32 9 axes · Ø 32 mm bar capacity · sub-spindle
Details
Swiss-type lathe with live tooling, Y-axis and separate back machining. LNS bar feeder and long parts adapter for producing long parts.
- Hyundai-Wia LM1800TTSY 2 servo turrets · Ø 65 mm · cobot
Details
12 tools per turret, BMT55P. 22 kW spindle motor on both spindle 1 and spindle 2, 5,000 rpm. Travel X1–X2 165–195 mm, Z1–Z2 700/720 mm, Y ±50 mm and ZB 668 mm. Hanwha HCR-12 cobot and LNS Quick Load Servo 80 S2 bar feeder.
- Doosan PUMA 2500 SY 5 axes · Ø 76 mm spindle bore
Details
Live tooling and LNS Quick Load Servo 80 S2 bar feeder.
- Emco Turn 365MC 5 axes · Ø 65 mm bar capacity
Details
Live tooling, sub-spindle and Y-axis. Kama bar feeder.
- Cincinnati Hawk TC-150 2 axes · Ø 65 mm bar capacity
Details
LNS bar pusher.
- Leadwell LTS 2 axes · Ø 46 mm bar capacity
- Colchester Mascot 1600 Manual · 1 machine · Ø 85 mm bar capacity
- Colchester Turret lathe Manual · 1 machine
Details
For small series, prototypes and one-off parts.
Milling machines
- HAAS VF-2SS X 762 · Y 406 · Z 508 · 12,000 rpm
Details
Vertical CNC machining centre with 22.4 kW spindle power, 40 taper and side-mount 30+1 tool changer.
- Doosan VC 510 X 762 · Y 516 · Z 570
Details
Spindle speed 12,000 rpm and rotary pallet changer.
- Leadwell MCV-OP X 500 · Y 400 · Z 400
Details
Multi-operation machine with a spindle speed of 6,000 rpm.
- Storebro Manual mill 1 machine
Details
For small series, prototypes and one-off parts.
Measuring machine
- DEA Global Classic X 700 · Y 1000 · Z 500 · 2.3 µm tolerance
Details
Coordinate measuring machine with a Tesa-star indexing probe head.
Grinding machine
- Garboli LPC 300-Wet Tube grinder Ø 5–114 mm
Details
From rough grinding to a polished finish.
Contact us for more information
Is there something you need that we have not mentioned? Contact us and we will be glad to help.
